不銹鋼閘閥適用于公稱壓力PN1.6～16.0MPa,工作溫度≤-29℃～550℃的石油、化工、水力、火力電站各種系統的管路上，切斷或接通管路介質。適不銹鋼閘閥用介質為：水、油品、蒸氣、及酸、堿、氨、尿素、含硫天然氣等。 不銹鋼閘閥結構特點
1、選材考究，符合國內外相關標準，材料的全面質量高。
2、符合國內外先進標準的要求，密封可靠、性能優良、造型美觀。
3、密封副配對先進合理，閘板和閥座的密封面采用不同硬度的司太立（Stellite）鈷基硬質合金堆焊而成，密封可靠、硬度高、耐磨、耐高溫、耐腐蝕、抗擦傷性能好、壽命長。
4、閥桿經調質及表面氮化處理，有良好的抗腐蝕性、抗擦傷性和耐磨性。
5、采用楔式彈性閘板結構，中大口徑設置推力軸承，磨擦力小，并配有撞擊手輪，啟閉輕松自如。
6、可采用各種配管法蘭標準及法蘭密封面形式，滿足各種工程需要及用戶要求。
主要零件材質
零件名稱ZG1Cr18Ni9Ti 304 CF8ZG00Cr18Ni10 304L CF3ZG1Cr18Ni12Mo2Ti 316 CF8MZG00Cr17Ni14Mo2 316L CF3M閥體/閥蓋0Cr18Ni900Cr18Ni100Cr18Ni9Mo200Cr18Ni10Mo2閘板0Cr18Ni900Cr18Ni100Cr18Ni9Mo200Cr18Ni10Mo2閥桿0Cr18Ni900Cr18Ni100Cr18Ni9Mo200Cr18Ni10Mo2閥桿螺母鋁青銅填料PTFE編織PTFE編織PTFE編織PTFE編織墊片304+PTFE304L+PTFE316+PTFE316L+PTFE壓蓋0Cr18Ni900Cr18Ni100Cr18Ni9Mo200Cr18Ni10Mo2螺栓不銹鋼螺母不銹鋼手輪球墨鑄鐵、鑄鋼
主要連接尺寸型號公稱通徑尺寸LDD1D2b-fz-ΦdHD0Z41W-1.6MPa1513095654514-24-1417012020150105755514-24-1420012025160115856514-24-14215140321801351007816-24-18260160402001451108516-34-182902005025016012510016-34-183452206526518014512018-34-183602408028019516013520-38-1838528010030021518015520-38-1843030012532524521018522-38-1852032015035028024021024-38-2361035020040033529526526-312-2376540025045040535532030-312-2589545030050046041037530-412-25114550035055052047043534-416-25120055040060058052548536-416-30140060045065064058554540-420-30150065050070070565060844-420-34163070060080084077071848-520-411830800
主要連接尺寸
型號公稱通徑尺寸LDD1D2b-fz-ΦdHD0Z41W-2.5MPa1513095654516-24-1417012020150105755516-24-1420012025160115856516-24-14215140321801351007818-24-18260160402001451108518-34-182902005025016012510020-34-183452206526518014512022-38-183602408028019516013522-38-1838528010030023019016024-38-2343030012532527022018828-38-2552032015035030025021830-38-2561035020040036031027834-312-2576540025045042537033236-312-3090045030050048543039040-416-30113050035055055049044844-416-34125055040060061055050548-416-34143060045065066060055550-420-34152065050070073066061052-420-41165070060080084077071856-520-411850800
主要連接尺寸
